Short Description:

  Specification Unit X2010 X2012 X2014 Max. travel Length mm 2000/3000/4000 Width mm 1300 1400 1800 Height mm 1000 1000/1200 Distance between columns mm 1440 1600 1920 Table size Length mm 2000/3000/4000 Width mm 1000 1250 1400 Table feeding speed Feed mm/min 20-360 25-450 Rapid travel mm/min 1050 1300 Spindle taper 7:24, ISO50 Spindle speed step r/min 6steps  82-505 Spindle swivel angle ±35° Feed rate of milling head mm Along the cross rail:65/320/890...
