CNC Lathe Machine CK6136
CNC LATHES FEATURES:
high rigidity pedestal and wider lay board are suitable for heavy cutting
four station electric turret
inverter stepless speed
| S. No. | Description | HOTONCK6136/750mm |
| 1 | 2 – Axis Horizontal Lathe | X axis:750mmZ axis:500mm |
| 2 | Swing over bed: | 360 |
| 3 | Controller: | FANUC |
| 4 | Distance between centers: | 750 |
| 5 | Spindle speed: | 150-2000 |
| 6 | Spindle Bore: | 52 |
| 7 | Spindle Taper | A2-6 |
| 8 | 3 jaws through hole Chuck hydraulic with a set of soft and hard jaws. | YES |
| 9 | Hydraulic Tool Post | Yes, confirm 4 tool postBut Only can be electric |
| 10 | Tail Stock | YES |
| 11 | X/Z Rapid Traverse | 8/10 |
| 12 | Spindle motor: | 5.5KW |
| 13 | Voltage: | OK |
| 14 | Including close loop feedback system (Servo), AVR, Auto Coolant System, Splash Guard, Tool Kit, Auto Lubrication, 3 color light, MPG, RS 232 & USB Interface, with necessarycutting tools. Operation & Maintenance | close loop feedback system (Servo),AVR,Auto Coolant System,
Splash Guard, Tool Kit, Auto Lubrication, 3 color light, MPG, RS 232 & USB Interface, with necessary cutting tools. Operation & Maintenance Manuals. |
