Punch Shear Q35Y-40
FEATURES:
|
Model |
Q35Y-40 |
|
Punching Pressure (T) |
200 |
|
Max. cutting thickness of sheet plates (mm) |
40 |
|
Material strength (N/mm²) |
≤450 |
|
Angle of Shear (°) |
8° |
|
Flat bar shearing (T*W)(mm) |
40*335 30*600 |
|
Max. length of cylinder stroke (mm) |
100 |
|
Trips frequency (times/min) |
8-16 |
|
Depth of throat (mm) |
600 |
|
Max. punching diameter (mm) |
40 |
|
Motor power (KW) |
18.5 |
|
Overall dimensions (L*W*H)(mm) |
2800*1100*2500 |
|
Weight(kg) |
6400 |
Types of profiled steel for shearing (If you want Joist or Channel, need special order)
| Steel category | RoundBar | Square Bar | Equal Angle | T Bar | I-iron | Channelsteel | |||
| 90° Shearing | 45° Shearing | 90° Shearing | 45° Shearing | ||||||
| Section view | |||||||||
| Q35Y-40 | 70 | 60*60 | 200*200*18 | 80*80*10 | 200*200*18 | 80*80*10 | 280*124*10.5 | 300*89*11.5 | |
