High-Precision CNC Lathe TCK6350 & ZX7045 Milling Machine by Hoton

Wholesale Cnc Lathe Tck6350 - Bench Milling Drilling Machine ZX7045 – Hoton

Short Description:

VERTCIAL DRILLING AND MILLING MACHINE FEATURE: ZX7045 not the same as ZX45, except that ZX7045 is equipped with Worktable power feed(longitudinal), Lifting motor with Big Electrical box, 2step motor with 12 steps speed iron casting foot stand and oil pan which can improve the machining accuracy and producing efficiency. Milling drilling, tapping, boring, reaming; Head swivels 360° ; Micro feed precision; Super high column, Wide and big table, Gear drive, lower noise.; Heavy-duty tapered rolle...

Send email to us Download as PDF

Product Detail

Product Tags

Feedback (2)

As for aggressive costs, we believe that you will be searching far and wide for anything that can beat us. We can state with absolute certainty that for such high-quality at such rates we have been the lowest around for Grinder My4080 , Lathe , Machining Centre Mill 850 , In addition, we would properly tutorial the purchasers about the application techniques to adopt our items plus the way to select appropriate materials.

Wholesale Cnc Lathe Tck6350 - Bench Milling Drilling Machine ZX7045 – Hoton Detail:

VERTCIAL DRILLING AND MILLING MACHINE FEATURE:

ZX7045 not the same as ZX45, except that ZX7045 is equipped with Worktable power feed(longitudinal), Lifting motor with Big Electrical box, 2step motor with 12 steps speed iron casting foot stand and oil pan which can improve the machining accuracy and producing efficiency.
Milling drilling, tapping, boring, reaming;
Head swivels 360° ;
Micro feed precision;
Super high column, Wide and big table, Gear drive, lower noise.;
Heavy-duty tapered roller bearing spindle, Positive spindle lock, Adjustable gibs on table

SPECFICATIONS:

MODEL	ZX7045
Max.drilling capacity(iron/steel)	31.5/45mm
Max.mill capacity(face/end)	80/32mm
Spindle taper	MT3/MT4/R8/ISO30
Worktable size	800×240mm
Worktable travelX/Y	570/230mm
Head tilt left right	90°
Spindle travel	130mm
Spindle nose to worktable	470mm
Spindle center to column surface	285mm
Spindle speeds range(2 steps)	12steps:75-3200r/min
motor	0.85/1.1kw
N.W/G.W	300/350KG
Packing size(L×W×H)	1140×960×2240mm
20’Container	12 sets
