Short Description:

Model Unit LD100A LD100B Valve stem dia. mm 3.5-20 3.5-20 Valve head dia. mm 12-100 12-100 Valve length mm 70-450 70-450 Angle grinding range degree 10-57 10-57 Main wheel diameter mm 200 200 Cup wheel diameter mm 100 100 Main wheel width mm 15 15 Grinding wheel travel mm 90 90 Valve feed travel mm 90 90 Spindle motor Power w 750 750 Speed rpm 3600 3600 Valve driving motor Power w 180 180 Speed rpm 120-750 120-750 Coolant motor Power w 100 100 Power suppl...
